Check the DCP and SIM Status:

  1. Try calling the phone number of the device: If the call is answered you know, the DCP is powered on, the Sim Card is working, and it is attached to the network. The device should then be programmable by SMS.
  2. If when calling the device phone number the call does not go through or goes directly to voice mail; wait 5 minutes and try calling the device again a few times. If there is no change then this would indicate either that unit is currently dialling out to another phone number or there is a fault with the device and an engineer will need to attend site to either power cycle to unit or swap it out completely



SMS Troubleshooting:

  1. SMS Troubleshooting: To contact a DCP send an SMS message to the device phone number in the exactly the following format: Pin1234,P0XX where XX is the parameter you want to check or modify.
  2. Send: Pin1234,P003? Check the DCP Firmware. You can also check if a device is 2G or 4G by looking for either GSM R2 (2G) or GSM R6 (4G). you can expect an SMS response within 5 minutes.
  3. Send: Pin1234,P005? SIM Card CCID Number - useful when creating or checking a Hub Installation. If the communication
  4. Send:  Pin1234,P007? Useful for checking number of connected DAU’s and what shaft they are configured as. C1000 shows there is 1 cabin DAU in shaft 1. P1110 would show there are 3 Pit Phones installed in Shafts 1, 2 & 3.
  5. Send:  Pin1234,P0941 Force a background test (DCP will try to contact Avire Hub)
  6. Send:  Pin1234,P0951234567890 Remote reset of the DCP. Effectively a reboot of the device, no settings are lost.
  7. Send:  Pin1234,P0947xxxxxx Force an alarm call to any number, replace xxxxxx with your own phone number to test.
  8. Send:  Pin1234,P091011 P091 is the super setting parameter. Setting this parameter to 011 will set the DCP to Default settings for an Avire SIM and connecting to the Avire Hub.

Avire SIM QR Code

  1. This QR code contains default settings for the Avire SIM and Avire Hub and contains the key settings to get the device working and connected. Scan it and send SMS to the device removing the Avire SIM APN settings (P060,P061,P062) if required.
